Polygon Mountain Bikes XC Sport Series Rayz 1 Rayz 2

Polygon Rayz 1 New White
Bicycles price : USD 265 / Rp. 3.500.000

Rayz 1 is designed for riders who require dual suspension platforms for "Good Time" riding in all fields. The design is inspired by mountain bike geometry, Rayz 1 is equipped with a lightweight ALX Alloy Dual Suspension Frame and 26 "wheel sizes for a more comfortable cycling position.

Specification :

Frame:

AL6 Alloy Dual Suspension Frame

Front Fork:

Zoom Fuego 100mm Travel

Rear Suspension:

Kind Shock KS-258

Shift Lever:

Shimano ST-EF41

Derailleur Front:

Shimano FD-TZ30

Derailleur Rear:

Shimano Tourney RD-TZ31

Brakes Front:

Power BX-351 Mechanical Disc Brake

Brakes Rear:

Power BX-351 Mechanical Disc Brake

Brake Levers:

Include Shifter

Pedals:

VP-560 Pedals

Crankset:

Cyclone CTL3-324P7S4 24/34T x 170mm

Bottom Bracket:

BB Set CH-63-2

Chain:

KMC Z-50

Cassette:

Shimano MF-TZ21-7

Hub Rear:

Steel Hub 32H

Hub Front:

Steel Hub 32H

Rim:

Alloy Rims

Spokes Nipples:

Stainless steel spokes

Tires:

Kenda Koyote 26X2.10

Saddle:

Polygon saddle

Seatpost:

Steel seatpost 27.2X300mm

Stem:

Steel handle stem 25.4mm

Handlebar:

Steel handle bar Width 640mm, Rise 20mm, Barbore 25.4mm

Headset:

Strummer ST188

Polygon Rayz 1 White
Bicycles price : USD 265 / Rp. 3.500.000

Specification :

Frame:

ALX Alloy Dual Suspension Frame

Front Fork:

Zoom Fuego 100mm Travel

Rear Suspension:

Zoom Fuego 100mm Travel

Shift Lever:

Shimano ST-EF41 Left, and Right

Derailleur Front:

Shimano FD-TY10 TOURNEY

Derailleur Rear:

Shimano TOURNEY RD-TZ31 7Sp

Brakes Front:

Mechanical Disc Brake

Brakes Rear:

Mechanical Disc Brake

Brake Levers:

Include Shifter

Pedals:

VP Plastic

Crankset:

Cyclone Hi-Ten 42/34/24T x 170mm

Bottom Bracket:

BB Cup CH-63-2

Chain:

KMC Z50

Cassette:

Shimano MF-TZ21-7, 7 SP, 14-28T

Hub Rear:

Hi-Ten Hub 32H

Hub Front:

Hi-Ten Hub 32H

Rim:

Alloy Rims

Spokes Nipples:

Stainless steel spokes

Tires:

Kenda koyote 26x2.10

Saddle:

Foming Saddle

Seatpost:

Hi-Ten 27.2x300mm

Stem:

Hi-Ten 25.4mm

Handlebar:

Hi-Ten Width 640mm, Rise 20mm, Barbore 25.4mm

Headset:

Strummer Alloy Caged Bearing

Polygon Rayz 2 Black
Bicycles price : USD 329 / Rp. 4.350.000

Rayz 2 becomes a full suspension bike suitable for you who want a comfortable cycling in the Cross Country field. The XC Sport series is designed with designs inspired from the geometry of mountain bikes. Rayz 2 is equipped with a lightweight AL6 Alloy Frame dedicated to those of you who are keen to improve biking techniques.

Specification :

Frame:
    AL6 Alloy Dual Suspension Frame
Front Fork:
    Suntour SF16-XCT-DS-26
Rear Suspension:
    Kind Shock KS-258
Shift Lever:
    Shimano ST-TX800
Derailleur Front:
    Shimano FD-M313 Altus
Derailleur Rear:
    Shimano Altus RD-M310-L
Brakes Front:
    Tektro MD-300-F Mechanical Disc Brake
Brakes Rear:
    Power BX-351 Mechanical Disc Brake
Brake Levers:
    Include Shifter
Pedals:
    VP-195E Alloy Pedals
Crankset:
    Prowheel MA-A543 42/34/24 x 170mm
Bottom Bracket:
    BB Set CH-46
Chain:
    KMC Z-7
Cassette:
    Shimano CS-HG200-8, 8 SP,
Hub Rear:
    Joytec D142DSE(D142TSE)
Hub Front:
    Joytec D041DSE
Rim:
    Alloy Rims
Spokes Nipples:
    Stainless steel spokes
Tires:
    Kenda K901F 26X2.10
Saddle:
    Aifeit Saddle
Seatpost:
    Entity Expert Alloy Seatpost 27.2mm x 350mm
Stem:
    Entity Expert Alloy Stem 31.8mm
Handlebar:
    Entity Expert Alloy Width 680mm, Rise 0.5, Barbore 31.8mm
Headset:
    Strummer ST188 Alloy Caged Bearing

Polygon Rayz 2 Charcoal
Bicycles price : USD 329 / Rp. 4.350.000

Rayz 2.0 becomes a dual suspension bike that is suitable for riders who want comfortable cycling in all terrain. The design is inspired by mountain bike geometry, Rayz 2.0 features a lightweight Alutech Frame and Shimano Altus 24 speeds for more comfortable cycling.

Frame:
    ALX ALLOY CROSS COUNTRY, 4-BAR SUSPENSION SYSTEM, 3.9” TRAVEL, 10X135 QR
Front Fork:
    SR SUNTOUR XCT HLO, TRAVEL 100MM, STANDARD STEERER
Rear Suspension:
    KINDSHOCK KS-258, 500LBS, M8X22MM
Shift Lever:
    SHIMANO ST-TX800
Derailleur Front:
    SHIMANO ALTUS FD-M313
Derailleur Rear:
    SHIMANO ALTUS RD-M280
Brakes Front:
    TEKTRO MD-M300, MECHANICAL
Brakes Rear:
    TEKTRO MD-M300, MECHANICAL
Brake Levers:
    SHIMANO ST-TX800
Pedals:
    ALLOY STANDARD PEDAL
Crankset:
    LASCO 42X34X24T, 170MM
Bottom Bracket:
    CAGED BEARING
Chain:
    KMC Z-7
Cassette:
    SHIMANO ALTUS CS-HG31, 11-32T
Hub Rear:
    ALLOY, 10X135MM
Hub Front:
    ALLOY, 9X110MM
Rim:
    ALLOY RIMS, SINGLE WALL
Spokes Nipples:
    STAINLESS STEEL SPOKES
Tires:
    KENDA KOYOTE, 26”X2.10”
Saddle:
    POLYGON SADDLE, STEEL RAIL
Seatpost:
    ENTITY OE, ALLOY, 27.2X350MM
Stem:
    ENTITY OE, ALLOY, 80MM
Handlebar:
    ENTITY OE, ALLOY, 680MM
Headset:
    POLYGON EXTERNAL CAGED BEARING
